MPEG2/4 DVB T2 HEVC H.265 Set Top Box USB 2.0 For PVR USB Software Upgrade

SHENZHEN KINGTECH INDUSTRY CO.,LTD
Contact Now
    Buy cheap MPEG2/4 DVB T2 HEVC H.265 Set Top Box USB 2.0 For PVR USB Software Upgrade from wholesalers

    Buy cheap MPEG2/4 DVB T2 HEVC H.265 Set Top Box USB 2.0 For PVR USB Software Upgrade from wholesalers
    • Buy cheap MPEG2/4 DVB T2 HEVC H.265 Set Top Box USB 2.0 For PVR USB Software Upgrade from wholesalers

    MPEG2/4 DVB T2 HEVC H.265 Set Top Box USB 2.0 For PVR USB Software Upgrade

    Ask Lasest Price
    Brand Name : KINGTECH
    Model Number : 220mm T2 Receiver
    Certification : CE,ROHS,FCC
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 1,000,000pcs
    Delivery Time : 20-30days
    • Product Details
    • Company Profile

    MPEG2/4 DVB T2 HEVC H.265 Set Top Box USB 2.0 For PVR USB Software Upgrade

    Dvb-T2 H.264 Mpeg2/4 Usb 2.0 For Pvr Usb Software Upgrade Dvb-T2 Set Top Box

    Product Name
    DVB-T2
    Solution
    MSTAR-MSD7T10
    Tuner
    Rafael R836
    Memory
    32X16Mbit DDR2 Frequency1066
    MPEG2/4 DVB T2 HEVC H.265 Set Top Box USB 2.0 For PVR USB Software Upgrade
    • Product performance description

    A terrestrial digital television receiver (also known as a terrestrial digital television set-top box) means that the receiver can receive signals from a terrestrial digital transmitter.
    The latest model in 2021, with a novel case, looks more advanced 110mm / 120mm / 140mm / 168mm / 220mm / 260mm Various sizes to choose from, and more than one hundred shells to choose from
    Specifications
    Model No
    DVB-T2 H.264/H.265/HEVC
    Hardware
    CPU
    MSTAR-MSD7T10 MIPS 34Kf@600MHz
    Memory
    32X16Mbit DDR2 Frequency1066
    Flash
    32M bytes
    Demodulator Type
    Integrated in the main chipset
    TUNER
    Rafael R836
    Front Panel
    red LED Standby,green LED Lock
    USB 2.0 Embedded One Host,
    4-digit LED display on front panel
    Panel KEY, POWER, CH+ ,CH-
    Rear Panel
    Tuner RF input connector
    IEC-162-2( Female)
    Tuner RF Loop through connector
    IEC-162-2( Male)
    HD V1.3/V1.4
    RCA CVBS AL AR Connector x1
    Ypbpr RCAx1
    Coaxial x1
    Power AC100~240V 50Hz/60Hz
    Demodulation
    Terrisal Receiver Standard
    DVB-T2/T(EN_302755 V1.3.1/EN 300744)
    Input RF Frequency
    48~866MHZ
    Bandwidth
    6MHz,7MHz,8MHz
    Constellation
    QPSK 16-QAM 64-QAM and 256-QAM
    FEC
    1/2, 3/5,2/3, 3/4,4/5,5/6
    Guard Interval
    1/128 1/32 1/16 19/256 1/8 19/128 1/4
    FFT Mode
    2K/ 8K/32K
    Support
    Support Single and multiple PLPS
    Input level
    -83 - -5dBm
    Sortware Features
    •Fully comply with DVB-T/T2 and H.264, MPEG-2/4 H.265/HEVC Standard
    •The maximum speed of the traffic flow of at least 50 Mbit / sec
    •Support 3D interface
    •Sleep Timer
    •Support teletext/subtitle/muti-language
    •Powerful and highly effective 7-day EPG function
    •AUTO, 16:9 Pillar Box, 16:9 Pan G Scan, 4:3 Letter Box, 4:3 Pan G Scan, 4:3 Full, 16:9 Wide Screen
    •USB 2.0 for PVR,TIMESHIFT,software upgrade and media files playback
    •Video output resolution: 480i/576i/480p/576p/720p/1080i/1080P
    •Support Digital Dolby AC-3
    Decoder
    Video Decoder
    Compliant with: MPEG-4 part10/MPEG-2 ISO/IEC 13818
    MPEG-4 Simple/Main/Advanced Profile@LEVEL3(10Mbps)
    MPEG-2 Main Profile# Main Level(15Mbps)
    H.264 MP#L3(10Mbps).H.264 HP L4.1(25Mbps)
    Audio Decoder
    MPEG-1, MPEG-2 (Layer I/II), MP3, AC-3 (Dolby Digital), AAC-LC, WMA E-AC-3
    (Dolby Digital Plus) decoding HE-AAC 5.1 multi-chhanneldecoding
    MediaCodec
    avi. mpg, .dat, .vob, .div, .mov, .mkv, .jpeg, .ts etc
    Audio Codec
    WMA,MP3,AAC (.wma,.mp3,m4a)
    Video Decoder
    JPEG, BMP, PNG
    Optional DTS, Dolby Digital, Dolby Digital Plus, RM/RMVB, Divx,DRA License.

    MPEG2/4 DVB T2 HEVC H.265 Set Top Box USB 2.0 For PVR USB Software Upgrade

    MPEG2/4 DVB T2 HEVC H.265 Set Top Box USB 2.0 For PVR USB Software Upgrade

    MPEG2/4 DVB T2 HEVC H.265 Set Top Box USB 2.0 For PVR USB Software Upgrade

    MPEG2/4 DVB T2 HEVC H.265 Set Top Box USB 2.0 For PVR USB Software Upgrade

    MPEG2/4 DVB T2 HEVC H.265 Set Top Box USB 2.0 For PVR USB Software Upgrade

    KINGTECH has been a leading company in consumer electronics product since 2011.Our major products in include Set

    Top Box(DVB, IPTV, OTT), Home Projector, IP/Web Camera,Finder, and Smart home products.As the frist -class electronics

    enterprise in china and as business is the intensely increased, KINGTECH's factory coversover 30,000 square meters located

    at Gongming ,Shenzhen, which is a low carbon city. Our factory has introduced the Quality Management System ISO9001:2000 ,

    Environmental Management System ISO14001:2004,BSCI system and in correspondence with ROHS,CE, UL,FCC FDA and so

    on.we could always gurantee the reliable quality with competitive price.
